High speed large format kebab printer
The kebab printer is a machine that can print patterns on cylindrical materials, and the uv ink used by the printer. The kebab printer is a technical upgrade version of the uv flatbed printer. A rotating shaft is added to the printer platform, and the printing software is upgraded to match the cylindrical printing function. Therefore, the kebab printer has both the cylindrical uv printing characteristics and the function of any flatbed printer.
 |  |  |
1.Automatic height detection system
2.Anti-collision system
3.Ink tank heating system
4.Color-White-Color & Color-White-Varnish solutions for optional
5.UV LED curing system
6.Imported guide+Screw drive.imported DC srvo motor.
Machine | YF-7590T UV flatbed printer | |
Print head | Toshiba CE4 gray level piezoelectric nozzle | |
Head No. | 2-8 | |
Print mode | 4C/6C/4C+W/6C+W/4C+W+V/6C+W+V | |
Print width | 750mm x 900mm | |
Print speed | 6 Pass | 8㎡/h |
8 Pass | 6㎡/h | |
12 Pass | 4.5㎡/h | |
Print resolution | 1200*600 DPI | |
Print materials | Galass、Acylic、Wooden、Ceramic tiles、Metal sheet、PVC board、Foamboard、3C product and etc. | |
Print height | ≤150mm | |
Curing system | LED water cooling system | |
Input format | TIFF/PDF/JPEG/EPS | |
RIP Software | Photoprint/Onyx/Caldera/Colorget | |
Data connection | USB3.0 | |
Input power | 220VAC(±10%) single phase ，50/60 HZ | |
Power | 2.5KW | |
Machine size/N W | 2.24m(L)*1.79m(W)*1.44m(H)/ 600KG | |
Packing size/G W | 2.34m(L)*1.9m(W)*1.55m(H)/ 650KG | |
1. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
2.What can you buy from us?
UV Printer,ECO Solvent Printer
3. Why should you buy from us not from other suppliers?
The company covers an area of 15000 square meters, has more than 200 employees, the core team has 15 yeas of industry experience, we together to create four series of products: Eco Solvent Printer, UV flatbed Printer, UV roll to roll Printer.
