YF-3220G UV Flatbed Printer - Product Introduction
YF-3220G, a large UV flatbed printer engineered for advertising printing. It uses Ricoh Gen6 print heads, boasting 40% higher precision than Gen5 and 10% faster speed. With LED cooling curing, it ensures long - life operation and low energy use. Ideal for 3C products, KT boards, signage, etc., it fits diverse ad - printing needs via flexible modes and media compatibility.
| Item | Detail |
| Model | YF - 3220G Meglev UV Flatbed Printer |
| Printhead | Ricoh Gen6 Industrial Grayscale Print Head |
| Print Modes | 4C/6C/4C + W/4C + W + V/2 + 4C/6C + W/3 + 4C/4 + 4C/5 + 4C/6 + 4C |
| Print Size | 3200mm×2000mm |
| Resolution | 720×1800DPI |
| Media Types | Glass, Acrylic, Wood, 3C products, etc. |
| Max Media Thickness | 100mm (＞100mm customizable) |
| Ink & Curing | LED UV ink; LED Curing System |
| Key Software | Photoprint/Onyx (RIP); TIFF/PDF (File) |
| Power Supply | 220VAC(±10%) Single Phase, 50/60HZ |
| Env. Requirement | 20℃ - 28℃, 40% - 60% humidity; Clean, ventilated space |
