Advanced UV Roll-to-Roll Printers: YF-3300Z & YF-5000Z Series
Our YF-3300Z and YF-5000Z series represent the forefront of UV roll-to-roll printing technology, designed for high-volume, industrial-grade production in the signage, soft signage, and decorative printing markets. These systems are ideal for businesses seeking high-speed, high-resolution output with the flexibility to print on a diverse range of media.
The YF-3300Z UV Printer is equipped with Ricoh Gen5 or Gen6 print heads, configurable with 2 to 9 heads, supporting versatile print modes including 4C/8C, 4C/8C+White, and multi-layer color combinations. It offers a maximum print width of 3200mm and achieves speeds of up to 66 nl/h in standard mode, with options for higher precision at reduced speeds. Meanwhile, the larger YF-5000Z model supports up to 12 Ricoh Gen6 print heads and a 5000mm print width, delivering even greater productivity with speeds reaching 100 nl/h. Both models maintain a high print resolution of 720×1800 DPI, ensuring sharp details and vibrant color reproduction.
These printers utilize eco-friendly LED UV curing technology, which instantly dries inks without VOC emissions. They support white ink and varnish options for creative and functional applications. Compatible with various soft substrates including backlit film, mesh, canvas, wallpaper, and leather (up to 5mm thickness), these machines are built for durability and ease of use with industry-standard RIP software and USB connectivity.
Operational requirements include a clean, temperature-controlled environment (20–25°C, 50–60% humidity) and a 220VAC power supply. The YF-3300Z has a compact footprint, while the YF-5000Z is designed for larger-scale operations. Both come with robust packaging for safe shipping and are backed with professional technical support and service.
Ideal for print service providers looking to expand into high-value, customized print applications, the YF series combines performance, reliability, and excellent output quality for the competitive industrial print market.
