YF-6090: Compact UV Flatbed Printer for Versatile Applications
The YF-6090 UV flatbed printer is a versatile and compact digital printing solution designed for small to medium-sized businesses seeking high-quality customization capabilities. Equipped with Epson printheads (model 13200-U1 or 11600-U1) in a triple-head configuration, this printer supports various color modes including 4C, 4C with white, and 4C with white and varnish, offering flexibility for both standard and specialty printing tasks.
With a print area of 600mm x 900mm and the ability to handle materials up to 150mm thick, the YF-6090 is ideal for printing on diverse substrates such as glass, acrylic, wood, ceramic, metal sheets, PVC, plastics, and promotional products. It delivers sharp, detailed outputs with a resolution of 1440 dpi, ensuring professional-grade image quality for decorative, functional, and industrial items.
The system uses eco-friendly UV-curing ink (VOC-free) and features an LED curing system for instant drying and reduced energy consumption. Operators can benefit from its user-friendly interface, support for popular file formats including TIFF and PDF, and seamless data transfer via USB 2.0. Compatible with widely-used RIP software such as Photoprint and RINR, it integrates easily into existing workflows.
Power requirements include a 220VAC (±10%) single-phase supply at 50/60 Hz, with a total power consumption of 2.8 kW. The machine's compact dimensions (1680mm L x 1640mm W x 1000mm H) and net weight of 220kg make it suitable for smaller production spaces. Shipping is facilitated with secure packaging, bringing the gross weight to 255kg.
For optimal performance, it is recommended to install the printer in a clean, low-dust, and well-ventilated environment with a stable temperature between 20°C–25°C and humidity levels of 40%–60%.
Ideal for personalized product manufacturing, promotional items, and short-run industrial applications, the YF-6090 combines performance, ease of use, and professional results in a space-efficient design.
